muffle oven

muffle oven

Model:PT-1200M

Description:The muffle oven consists of high purity alumina polycrystalline fiber brick.Its double layer between the furnace shell is equipped with air cooling system,which makes temperature cool and rise quickly.

Inquire Now

Introduction:

Features of muffle oven :
1. Operation Temperature: 1100℃ ( 1200℃ for short time).
2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
3. Three sides resistance wire coil for fast and uniform heating.
4. Heavy duty double layer structure with cooling fan. Lower temperature in outside case.
5. 0.5" diameter observation window made of quartz glsss, allows users to see inside chamber during heating operation.
6. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
7. Power control with 30 segments programmable.

We have a wide range of different optional function furnace to meet different heating requirement, also we accept customer design furnace R&D working, please email us your specific requirement, we will recommend most reasonable choice for you, thanks!

Descriptions of muffle oven :

Chamber Size 200x200x200mm (WxHxD)
Working Temperature 1100℃
Maximum Temperature 1200℃
Heating Rate 0~15℃/min (suggestion: ≤10℃)
Temperature Accuracy +/-1℃
Temperature Controller 30 steps programmable and auto control
Heating Element Resistance Wire
Voltage AC 220V, Single Phase, 60/50 Hz (or according to your requirement)
Max. Power 4 KW
Outside Size 550 x 540 x 820 mm
Net Weight 100 Kg
Note: there are different chamber sizes for your choice.

Transaction process


  After-sales Service


1.We provide one year warranty for our equipment (Except the quick-wear part),Equipment damage or malfunction during the guarantee period due to equipment quality reasons, all be free maintenance.After the warranty expires, still offer lifetime and high quality service.

2.In case of failure in the process of equipment used, our company will make a deal as soon as possible, to ensure the normal operation of equipment.

3.Our company provide free equipment operation training and simple troubleshooting and maintenance training.

4.My company's technical staff can provide door-to-door service (product installation, debugging, maintenance, technical advice and instructions, etc.).

5.Our company provides transport services, packaging are carried out in accordance with the safety standard packing.Random complete technical data (user manual, maintenance manuals, relevant materials and accessories, random tools, etc.).

6.All the equipment has the CE certificate.
