Split type high frequency gold melting furnace

Split type high frequency gold melting furnace


Description:The equipment is used for precious metal melting ,with a fast speed, low wastage, stable performance;adopted quartz crucible or graphite crucible, easy operation,especially for small amount gold ,Siliver , platinum, copper, aluminum,palladium melting ,This furnace suits for laboratory test use .

Inquire Now

A. Light weight, small size and modular design
B. IGBT inversion technology, high-efficient conversion,LC series resonance
C. Environmental protection,easy operation, low labor intensity
D. Melting rapidly, heating evenly, no oxide layer, and using timer to make sure
E. equipped with water cooling system(optional)
Cabinet or split type of Gold melting Induction furnace for option.

Technicial Datas :
Model PT-S15KW
Maximum oscillating power 15KW
Maximum input current 24-30A
Input voltage Single phases 220V 50-60HZ
Voltage range 180~240V
Output frequency 30~80KHZ
Output heat current 200A~600A
Duty cycle 80%
Cooling water desire Water pressure≥0.2Mpa   water flux >3L/min
Timing function of the S15KW
Heat current and retain current 200A~600A
Heat time,retain time,cooling time 1~99 second
Size of the generator W20×H44×L46
Weight of the generato 18KG

Transaction process

  After-sales Service

1.We provide one year warranty for our equipment (Except the quick-wear part),Equipment damage or malfunction during the guarantee period due to equipment quality reasons, all be free maintenance.After the warranty expires, still offer lifetime and high quality service.

2.In case of failure in the process of equipment used, our company will make a deal as soon as possible, to ensure the normal operation of equipment.

3.Our company provide free equipment operation training and simple troubleshooting and maintenance training.

4.My company's technical staff can provide door-to-door service (product installation, debugging, maintenance, technical advice and instructions, etc.).

5.Our company provides transport services, packaging are carried out in accordance with the safety standard packing.Random complete technical data (user manual, maintenance manuals, relevant materials and accessories, random tools, etc.).

6.All the equipment has the CE certificate.
